Parameter:
| Portable design | Portable mini system; able to equipped with different external cameras based on applications. | |
| User interface | Support E-set, remote, Micro SD card, button configuration | |
| Language | English, Chinese (option customized) | |
| Security | Multiple grade secure password management | |
| Video | Input/output | Special external HD cameras |
| OSD | Overlays letters… like date /time,v ehicle ID, GPS,etc into the video | |
| Compression | H.265 with an industrial high-speed processor | |
| Dual-stream | Record with mainstreaming, net transmitting second streaming, picture snap the third streaming | |
| Resolution | 1080P/720P/D1 optional | |
| BitRate | D1: 512kbps/768kbps/1024kbps/1536kbps/2048kbps 720P: 1024kbps/2048kbps/3072kbps/4096kbps/5120kbps 1080P: 2048kbps/3072kbps/4096kbps/5120kbps/6144kbps |
|
| Live preview | Under AP mode, can achieve live video preview by mobile app | |
| Audio | Input | Bluetooth device input |
| Output | Bluetooth device output | |
| Compression | G.726 | |
| Record | Storage | Support 1pc 16G~128G micro SD card |
| Format | FAT32 | |
| Record search |
|
|
| Wireless transmit | Built-in 3G/4G module | |
| Compatible with GPRS, EDGE | ||
| Built-in WIFI, support spot configuration | ||
| Localization | Built-in GPS/BD/Glonass(option),Support AGPS. | |
| Firmware upgrading | Support Micro-SD card upgrading, network upgrading | |
| External port | Special port for data export, device recharging. | |
| Power supply & consumption |
Power management | on/off ,over-voltage protection |
| Battery capacity | 7.4V 2200mAh(16.2WH) | |
| Recharging time | <3 hours | |
| Working time | >6 hours | |
| Work Environment |
Temperature | -20℃ ~ +75℃ |
| Humidity | 10% ~ 95% | |
| Size | 50(W) x104(H) x27(D) mm | |
